Raspberry Pi 5 Model 8GB

Description

Greetings, Raspberry Pi enthusiasts! Its officialtheRaspberry Pi 5 has arrived!

Welcome to the cutting-edge Raspberry Pi 5 Model 8GB, the latest generation of this iconic computing marvel. Packed with a64-bit quad-core Arm Cortex-A76 processorclocked at 2.4GHz, the Raspberry Pi 5 boasts an impressive23 increase in CPU performancecompared to its predecessor, the Raspberry Pi 4.

Not stopping there, it delivers a substantial boost in graphics power thanks to its800MHz Video Core VII GPU, supportsdual 4Kp60 displayoutput via HDMI, and offers state-of-the-art camera capabilities courtesy of a reimagined Raspberry Pi Image Signal Processor. It promises a seamless desktop experience for consumers and opens new horizons for industrial applications.

Take a moment to explore the upgrades introduced by the Raspberry Pi Foundation in this brand-new generation of the Raspberry Pi 5 Model 8GBpocket computer. Building upon the significant hardware enhancements of the Pi 4, the Pi 5 comes equipped with a host of hardware and software improvements outlined below.

---

Applications

• Desktop-level computing and coding

• DIY media center and home server

• Robotics and AI-powered projects

• Industrial IoT gateways and automation

• Multi-camera computer vision applications

Features:

1. 2.4GHz quad-core, 64-bit Arm Cortex-A76 CPU, with 512KB L2 caches and a 2MB shared L3 cache
2. Video Core VII GPU
3. LPDDR4X-4267 8GB SDRAM
4. 2.4 GHz and 5.0 GHz 802.11ac Wi-Fi
5. Bluetooth 5.0 / Bluetooth Low Energy (BLE)
6. Micro SD card slot, with support for high-speed SDR104 mode
7. 2 USB 3.0 ports, supporting simultaneous 5Gbps operation
8. 2 USB 2.0 ports
9. Gigabit Ethernet, with PoE+ support (requires PoE+ HAT)
10. 2 4 lane MIPI camera/display transceivers
11. PCIe 2.0 x1 interface for fast peripherals
12. 5V/5A DC power (PD enabled)
13. Raspberry Pi standard 40-pin header
14. Real-Time Clock (RTC), powered by an external battery
15. On-board power button!!

---

Specification:

Item Type:

Dev. Board

Model Type

Pi 5

RAM Memory:

8GB

Model

Raspberry Pi 5 Model 8GB

Processor

64-bit Arm Cortex-A76 CPU

RAM

8GB LPDDR4 SDRAM

Connectivity

2 USB 2.0 Ports, 2 USB 3.0 Ports, Bluetooth 5.0, USB-C, Wi-Fi + Bluetooth Low Energy

GPIO

Standard 40-pin GPIO Header

Multimedia

H.265 (4Kp60 decode);

Video and Sound

2 micro HDMI ports (up to 4Kp60 supported), 4-Pole Stereo Audio and Composite Video Port

Clock Speed

2.4 GHz

On Board Ports

1 x DSI, 1 x Ethenet, 2 x Micro HDMI, 2 x USB 2.0, 2 x USB 3.0, 40-pin 2.54 mm (220 strip) GPIO, USB Type-C port

Micro-SD Card Slot

Yes, Supports high-speed SDR104 Mode

Operating Temperature (C)

-10 to 60

Length (mm):

85

Width (mm):

56

Height (mm):

8

Weight (g):

105

Shipping Weight 0.1 kg Shipping Dimensions 12 8 3 cm

---

Package Includes:-

1x Raspberry Pi 5 Model 8GB
