Temperature and humidity sensor waterproof probe SHT20 with bracket and waterproof coating

Description

This is a SHT20 I2C temperature & humidity sensor with waterproof probe. It comes with the 4C CMOSens SHT20 temperature & humidity sensor chip, and the probe has gone through dual waterproof protection. The SHT20 I2C temperature & humidity sensor adopt Sensirion new technique. Besides the capacitive type humidity sensor and the band gap temperature sensor, the chip contains an amplifier, A/D converter, OTP memory and a digital processing unit. To compare with early SHT1x series and SHT7x series, SHT20 shows better reliability and long-term stability. It can measure surrounding environment temperature and relative air humidity precisely. The Arduino SHT20 waterproof temperature & humidity sensor adopts dual waterproof protection.

Connection Diagram

Specification:-

• Operating Voltage: 3.3/5V
• Communication Interface: I2C
• Protection Class: waterproof anti-condensation
• RH Response Time: 8s (tau63%)
• Accuracy: 3% RH / 0.3
• Measuring Range: 0-100% RH / -40-125
• Dimension: 73mm * 17mm / 2.87 * 0.67 inches
• Weight: 44g

Package Include:-

1xTemperature and humidity sensor waterproof probe SHT20 with bracket and waterproof coating
